Functional characteristics
Short wave infrared, the wavelength has a very strong penetration. Directly into the paint, the basic temperature of the paint layer produces a rapidly increasing heat, and the water evaporated rapidly from inside to outside. When the chemical vibration frequency of the coating is the same, the possibility of cross-linking polymerization is increased to accelerate the curing of the paint. Therefore, the gloss of the paint is high, the mirror is clearer and the adhesion is strong. It is not easy to produce "orange peel tears" phenomenon, avoid rework and improve efficiency！
●The design of convection heat dissipation greatly improves the effect of heat dissipation
●Knob combination power switch independent control group switch
●Lacquer tube diameter 12mm rapidly rising temperature and heat inertia
●Infrared radiation intensity high infrared wavelength stabilization
●The heat response time is easy to control the temperature
Independent lamp control
Mechanical timing control
Non polar power regulation

input voltage

AC220V

Rated power

2KW

Lamp disc height adjustment

Manual adjustment

Preheating time

1-5min

drying time

1-5min

Working hours

5a

Working distance

000-800mm

Output time

60-70

baking time

800*800mm

weight

30Kg.

size

head 730*230*780
Pillar70*70*1550
base530*140*610
